I recently unified the codepaths for recording data, evaluating expressions "currently", and evaluating them historically. This was primarily so that I could finalize conditional breakpoints with arbitrary expressions.
Because they're unified, it made it straightforward to allow conditions to mix and match current and historical data, e.g. in this video val > val @ 0 is true when the current value is greater than the value at sample 0.
Previously, the assumption was that recording would always use be really simple expressions (e.g. variables, pointer derefs, struct member access etc), and that all the full expression work would be historical.

The new conditions play nicely with other major recent additions to &WhiteBox: breakpoint actions to enable/disable other breakpoints/inspections, and (auto-layouting) hardware breakpoints.

These solve the main things I find frustrating with data breakpoints in other debuggers that I've tried:

• Data breakpoint disable between runs (presumably due to ASLR & not knowing where to replace them).
  • Solution: auto-enable them at specific points in the code, reevaluating the expressions for addresses then.
• Data breakpoints on local vars trigger in some completely different callstack that you don't care about after the function finishes.
  • Solution: auto-disable them either at particular points in the code or when the function returns.

In the video:

• I place a sampling breakpoint both as a place to enable/disable the data breakpoint, and as a fixed point of reference for comparing val > val @ 0
• The data breakpoint is set to sample data and then continue execution
• I rerun multiple times with different conditions (including historical self-reference) and get a fresh timeline showing different all the times val was written to when the condition was true.
• (You can see all the changes for local vars on multiple levels of the stack, as well as watch expressions currently evaluating at the top level.)

I did my first &WhiteBox dev stream in a very long time and it went really well!

I added basic, but fully-functional support for hardware breakpoints, including exec/read/write triggers for all valid sizes.
It also has expression evaluation with immediate inline feedback on the address.

It already works with WhiteBox's sampling & timeline to let you see every change to some data, not just stop at the next one 😁
(You can use it to break at the next change as well...)
Ignoring the WIP/dev breakpoint UI, below you can see on the timeline every time val gets written to when parsing "236":

Major new upgrade to &WhiteBox's timeline incoming: showing data at multiple levels of the callstack at once!
(Here you can see n in [Stack 3] is changing at the same time as *out in [Stack 4].)

WIP shot of EXE callstacks across time with data from a selected function in &WhiteBox. You can switch between functions to show recorded data for each.
(Showing data for multiple functions at once is coming, but requires a rework of the UX model because it breaks the current assumption that there's only one expression per row)

&WhiteBox https://fxtwitter.com/whitebox_sys/status/1734239475176296811

&WhiteBox https://fxtwitter.com/whitebox_sys/status/1734210818294657078

&WhiteBox v0.122.0

New Features

• Add simple watch expressions for the timeline, with feedback messages and underlines for parse errors
• Add call stacks to timeline (including arguments & return values where captured)
• Add text scaling (Ctrl + =/Ctrl + -)
• Speed up data inspection, which bounds total running speed for user code
• Add right-click options to timeline values to copy to clipboard
• Visualize jumps in disassembly
• Add AT&T/Intel disassembly syntax options
• Add support for non-trivial copy constructors

Improvements & Fixes

• Better handling for anonymous records
• Improve font rendering with DirectWrite, FreeType, and TrueType backends
• Improve C++ constructor handling
• Show min/max values for timeline expressions
• Improve data tree value graph
• No longer break on Linux signals that are recommended to be ignored by default (e.g. SIGWINCH - change window size)
• Animate the status bar colour when new messages are added to the console
• Fix emacs plugin port issue
• Fix misc issues; add resiliency to more edge-cases; reduce jank; ...

Known Issues

• Globals that are mutated and not reset in user code are not always consistently reset between runs (e.g. changing functions back and forth with a locked caller). Saving your code or using Compiler > Reset (Ctrl+Shift+R) forces them to be reset.

Get access to the latest version here: https://azmr.itch.io/whitebox

N.B. If you were on the WhiteBox discord (https://chat.whitebox.systems) you'd have known about this last week 😁

New &WhiteBox feature: call stacks!

Each level shows the arguments that function was called with, and the return value if it was recorded.

They're currently aligned to the inspected function, but this is likely to change as we move toward inspecting multiple functions at once.

On request from a non-HMN user, I've just added a right-click option to &WhiteBox for copying values from the timeline.
This can then be fed back into the function caller to rerun, starting with the given value (for simple data, not pointer nests)...
(N.B. it copies the value with the current formatting, so to make it a valid C initializer Struct member names needs to be disabled)

@philliptrudeau has done some great work adding a DirectWrite backend for the text rendering in &WhiteBox: small text now looks much better!
(ideally viewed at 100%)

I spent some extra time on this at the end of last week getting &WhiteBox's disassembly jump lines to merge when they have the same destination.

I'm quite pleased with how much it improves the overall legibility of the potential jumps.

Can you spot the codegen oddity in the disassembly?

Thanks to some prompting from @megawolf, the jumps in &WhiteBox's disassembly view are now also coloured by direction

I just added the option to use Intel syntax (as well as AT&T) in &WhiteBox's disassembly, as well as arrows showing the destination of each jump (unconditional jumps are brighter than conditional jumps)

A user got &WhiteBox working with @raysan5's raylib, and I realised I hadn't tried it yet myself. This was something that needed correcting immediately!
It became possible with the concurrency features @philliptrudeau worked hard to get into v0.116.0

There are still things to hammer out from the previous interaction model (when to rerun the code, LOD, recording selection...)

But take a look:
live, graphed data & an instant edit-run loop for games!

raylib made this very easy:

• download raylib-4.5.0_win64_msvc16.zip from https://github.com/raysan5/raylib/releases/latest
• add -I[...]/raylib/include to the compiler flags
• add [...]/raylib/lib/raylib.dll to the DLLs list
• connect to WhiteBox from an example raylib file
• start playing

◻️ WhiteBox v0.116.0 released!

Some highlights:

• Inspect data for code while it's running
• Inline timeline data graphs
• Faster but less detailed "black box only" recording option
• Greatly improved C++ support
• 10x Editor plugin
• Disassembly view
• (and a lot more!)

Huge thanks to @philliptrudeau for all the work he's done for this release 😀

See the devlog for more details: https://azmr.itch.io/whitebox/devlog/563116/whitebox-v01160

We accidentally turned &WhiteBox into a graphing calculator 😄

&WhiteBox now has a pretty good heuristic for determining uninitialized values, which means we can show them as distinct and not include them in min/max stats: 🥳
e.g. k is uninit until line 8 finishes

&WhiteBox now has a pretty good heuristic for determining uninitialized values, which means we can show them as distinct and not include them in min/max stats: 🥳

&WhiteBox timeline data visualisation part 3: using de-emphasis for the "non-value" part of the bar instead of emphasis for "value" part itself. To me this reduces visual noise, but I'd like to hear thoughts from others. The value colour is what was the normal bar colour... it might be worth increasing the contrast somewhat.
Importantly, it also obscures the text less.
(Ignore the fact that [line] is coloured as it was previously, synthetic values need to be handled slightly differently)

&WhiteBox Noticed a bug in the previous image as I was writing about unit size: there's an off-by-"1" in max value for floats, which visually halves the 0.0-0.9 range shown.
This is now fixed:

&WhiteBox Noticed a bug in the previous image as I was writing about unit size: there's an off-by-"1" in max value, which visually halves the 0-1 range shown.
This is now fixed:

&WhiteBox timeline data visualisation part 2: lines for integral values have a height based on the span/range of values for that expression. This is particularly useful for expressions with small ranges like booleans!
This is meaningful because integers have a "unit size" of 1, but floats don't really have that. I could use "smallest non-zero exponent" or "smallest difference between values" or even "ordinal rank of all seen values (sorted)". The last of these would work for integers as well with large ranges but few values. It's better for distinguishing between values but not so good at making the actual value perceptually apparent.

&WhiteBox timeline data visualisation, part 1: horizontal lines indicating value for primitive types

&WhiteBox is prepping to go native, reading PDBs for arbitrary executables in place of the DWARF it generates internally.
Unsurprisingly, @NeGate has been doing a great job on this! 😄
Here's WhiteBox inspecting its own PDB functions, showing line info & local variables

&WhiteBox Handmade Seattle demo is now public
https://twitter.com/whitebox_sys/status/1598824487084068864
https://www.youtube.com/watch?v=mNFDr33NbyQ

&WhiteBox
https://twitter.com/whitebox_sys/status/1577053893150019584

I've been working my way through the ANSI control codes standard (+ extras) for WhiteBox's new in-built console.

We're capturing stdout & stderr from the user's process, reading ~all controls & handling more graphical ones than many terminals!

Can yours do curly red underlines?

&WhiteBox https://twitter.com/whitebox_sys/status/1573418093531271169

Just playing around with a WIP build of WhiteBox after @phillip_trudeau has made some upgrades.

I'm really enjoying taking advantage of this breakout, full-width timeline 😀

(thanks to @ocornut for Dear ImGui + docking + viewports!)

I added a red line to the end of the &WhiteBox timeline when a run had an error that prevented the function from returning.
I also fixed the status message telling you what line the error occurred on.
(There's a new release coming very, very soon!)

I had a few minutes spare this morning so I rushed out a summary video of how MetaDocs is looking after the jam (apologies for lack of polish, I didn't have time to plan it out fully): https://youtu.be/kKppU0zcXjM

Highlights:

• reading clang's AST from JSON into C structures, deduplicating repeated nodes
• converting that into a more convenient structure for navigating symbols and their attached documentation comments
• starting to autogenerate a markdown-like syntax for symbols and attaching the documentation text
• evaluating constant expressions from the AST for enum values

Still to finish:

• representing primitive types in the same way as custom types
• finalising binary and JSON outputs
• complete example translating to a final HTML
• library methods to assist with references between documentation and symbols
• proper scoping of types

Mid-jam dev videos:
7: https://youtu.be/hgyVoYQeHFM
8: https://youtu.be/bujTibgXY5Y
9: https://youtu.be/TGmjuB506ww

&WhiteBox https://twitter.com/whitebox_sys/status/1534480349820071936

&WhiteBox now has a welcome screen with instructions on how to install the plugin for each editor, thanks to @BaremetalBaron

&whitebox https://twitter.com/whitebox_sys/status/1528796270797651968

&whitebox https://twitter.com/whitebox_sys/status/1519811544766369792

I'm really excited about this update to &WhiteBox - it adds the ability to call into other functions in your code (not just the function that's being recorded).
This means you can call main() (or something else that calls your function) and see how your function behaves with all of the parameters & extra context from runtime without having to input them manually.

It's now at a point where this seems to be working, it just needs to do a little tidying up after itself...

Reworked &WhiteBox's recording of the running process' memory to be faster, simpler, and to better capture pages changing protection/accessibility

I haven't shown much for &WhiteBox recently as it's all been pretty non-visual. Here's a little expression builder I made on stream for debugging expression evaluations.
It shows the value of that expression at a given sample of the run as well as a list of all the times the value changed during the run.

Having it as a builder means that I can enforce the validity of the expression, and it also means I don't have to handle shadowed variables with the same identifier as you would for text parsing. It's a little less clear how identities should be handled when taking a large span of time into account instead of just a single instant, so this lets me defer decisions about that.

WhiteBox happily running on Linux with 4coder 😁

WhiteBox is officially rendering on Linux 😄
Only a couple more things to port...

WhiteBox (real-time debugger) GUI improvement: limiting variables on the timeline to only show the time ranges when they're in-scope (implemented on stream).

@martijn I know you wanted to see this 😁

quick new UI mini-feature for WhiteBox: see all the points in the execution timeline that correspond to a location in the code (i.e. there's a highlight for every time the instruction pointer hits the code under the cursor)

I was cheating a bit before by determining what functions need to be compiled before starting to run.

I've improved the communication between the processes running & overseeing the code execution:
WhiteBox now has the option to defer a function's compilation until the first time it's called.

This opens up possibilities for optimization as well as adds support for using function pointers 😀

"WhiteBox ANNIHALATES Visual Studio in an EPIC debugger showdown"
hmm maybe too much...
"How the real-time feedback of WhiteBox will revolutionize the way you program"
... is this marketing? Am I doing it yet? 😁

This compares the process of getting feedback for a simple problem from a normal debugger and with WhiteBox. This is fairly low-hanging fruit as far as improvements go (conceptually at least), but I think it shows how much quicker & easier feedback should be for at least the common cases of writing code.

Jump to 1:20 if you just want to see how WhiteBox looks in use

It's been a while since I added any new features to WhiteBox (my real-time debugger), and I've been intending to implement a data timeline for ages: here it is in an early form 😀

People who've preordered will be getting a version of this in the next couple of days to start playing with.

I now have loads of information fairly easily queryable for adding new representations like this, before we even get to different types of data that we can collect!

I've just added a new feature to WhiteBox (my live code debugger/previsualizer) that's really been missing - the ability to add a length component to pointers, so that they can be treated as arrays 😀

For those unfamiliar, a quick overview of what's being shown here:

• the code in the box in the top right is providing arguments for and calling the code in the editor to the left.
• the bottom-right section is a mutant debugger-like data-tree
• the values highlighted red are those that changed just before the "breakpoint" on the position of the cursor
• there are 2 values for the last 3 elements of array because both are seen at some point in the run when the instruction pointer reaches the cursor
• (there is only 1 value for the first element because it's already been scaled before the first time the instruction pointer reaches the cursor - my first reaction was that something was wrong, but I'm pretty sure this is correct - WhiteBox is already correcting my misconceptions 😁)

I also realised there aren't any new features to add before I send out to the preorderers! I just have a few things to tidy up and then we're good to go 😀
If you'd like to be one of the vanguard with imminent access to the (buggy) alpha version, you can preorder WhiteBox with a 35% discount here https://azmr.itch.io/whitebox

I've started to update the colourscheme for WhiteBox (my live code debugger/previsualizer).
(I've yet to update the graphs)
red highlights data changed in statement before the editor cursor position
blue (and the graph) is showing all of the changes for a given variable

WhiteBox (live code previsualizer/debugger) now has global & per-variable data print options (proper cascading options and more UI feedback coming soon)

Variables that change in a loop shown inline - now working with struct members and eliding elements between the top and bottom 3 (easily changed to more/less)

Note the cursor is on line 11, before data.num has been set. Correspondingly, in the # (change number) column, there is one remaining change in value for data.num (which also means there's another change for data).

(if you're wondering why i has 33 values, it's because it's also recording after the final ++i, at which point the loop exits)

I added inline displaying of loop-value changes to WhiteBox. It's on it's way to something useful but definitely still needs some tuning

It's been a little while since my last devlog, so here's an update on some of the progress I've made.

• an actual GUI!
• familiar debugger-like data tree
• graph and tree-based exploration of variable changes over a function.
  Let me know what you think!
  https://www.youtube.com/watch?v=lZX8I0w7jJ4

Right, after some feedback from a few people and with the perspective of a new day I decided that my previous video was unreasonably difficult to follow, so I've reuploaded it with commentary and a visual indicator of what I'm talking about at any given time. If you found the previous version a bit lacklustre, please give this one a try: https://youtu.be/4T11-B7jXIk

Although this doesn't look like much, it represents quite a few months of work. Apologies for the silence, hopefully it makes sense. https://www.youtube.com/watch?v=r7v2EcTVUVs

successfully outputting MIDI with multiple instruments

Colourblind shader demo (play both at the same time)

closeup through a slightly grubby 10x loupe

Got my blit16 font running on a tiny 128x32 LCD screen (via arduino)

Progress is slow (sneaking in 20 mins here and there), but I got OpenGL working with the main drawing. Need to tweak some parameters now, the points are all wrong 😛

woo, OpenGL finally working (and drawing the primitives I need)!

Slight change to show another feature at the start

Added a couple of helpful new features to geometer (e.g. selecting & deleting points!)
